WPC Foam Board Making Machine / Three-layer WPC Construction Template Production Line
Quick detail:
1. Our production Lines have two extruders co-extrusion type and three extruders co-extrusion type. Our extruders adopt specially designed screw. We did lots of study from process to formula. The performance of our machinery and equipment reached the international advanced level.
2. The plates produced by our production line have no cracking and non-deformation in high temperature. Usually the template can be used for more than 30 times, and maximum can be used for 50 times.
3. The WPC plate has the same characteristics as wood boards: which can enailed, can be sawed, can be drilled, can be planed, can be sculptured. With the exclusive formula developed by our compamy, there is no need to granulate the material, which is cost saving and labor saving.
Description:
1. PVC and wood composite construction template production line is composed of twin screw extruder, board mould,vacuum shaping machine and nine roller haul-off machine, etc. Due to its unique screw structure and advanced technic and formula, the construction template board can bear high-temperature without deformation and bear low temperature without crack.
2. Main Features of PVC/WPC Foam Plate/ Board/Sheet Production Line
1).Wood-plastic mould ,resembling wood in appearance,is more fixed in size than wood without cracks,curls,protu berances,and cross grains,it has the features of better physical and chemical property,to ensure higher density and longer service life.
2).Wood-plastic mould can be reproduced like wood.It can be cut,planed,madea bond by glue or fastened with nalis or screws.It's easy to maintain.
3).Preserved from acid,alkali,corrosion,impervious to attacks by insects and rats,wood-plastic mould plates provide less moisture absorption.
3. This conical twin screw extruder is qualified for upvc,pvc,wpc powder extrusion directly to produce various kinds of plastic profile.
3.1.full set of mould can safisfy different kinds of flooring ,profile ,decking ,panel and other wpc products.
3.2.wpc product is very widely used nowadays!
3.3.automatic length accounting device for precise cutting
3.4.cutting machine ,adopt advanced Germany technology
3.5.stainless steel and pneumatic controlled
Specifications:
| Model | SJSZ-51 | SJSZ-55 | SJSZ-65 | SJSZ-80 | SJSZ-92 |
| Screw dia.(mm) | 51/105 | 55/110 | 65/132 | 80/156 | 92/188 |
| Max speed(rmp) | 40 | 38 | 38 | 37 | 36 |
| Main motor(kw) | 18.5 | 22 | 37 | 55 | 90 |
| Capacity(kg/h) | 80~100 | 100~150 | 150~250 | 250~380 | 380~700 |
| Center height(mm) | 1050 | 1050 | 1050 | 1050 | 1100 |
| Net weight(kg) | 3000 | 3500 | 4000 | 5500 | 8000 |
| L*W*H(m) | 3.6x1.1x2.1 | 3.6x1.1x2.1 | 4.2x1.5x2.4 | 4.7x1.5x2.4 | 6x1.6x2.5 |
Competitive Advantage:
1) We give you suitable suggestions according to your actual need.
2) Technical support: long available life
3) Under the right operation way, the screw and barrel is for 10000 working hours.
4) Our expert will answer any inquiry within 48 hours and it will be solved as soon as possible.
5) The customer can send the engineer to our company with training
6) Our engineer can be to the Buyer's company for installation and testing the lines.
7) The seller provides you with complete technical support documents and the relative drawings of the electric components written in Chinese and English.
